AMD Ryzen Embedded V1605B

AMD Ryzen V1605B

Der AMD Ryzen Embedded V1605B ist die embedded Variante des Consumer Ryzen 5 2500U. Der SoC beinhaltet 4 Zen Kerne (Quad-Core CPU) die von 2 - 3,6 GHz getaktet werden. Der TDP ist konfigurierbar zwischen 12 und 25 Watt (15 Watt nominell) und daher eignet sich die APU auch für schlanke und leichte Notebooks. Der L3-Cache beträgt beim 2500U 4 MB. Weiters ist eine Radeon RX Vega 8 getaufte Grafikkarte mit 8 CUs (512 Shader) integriert. Der integrierte Speichercontroller unterstützt maximal Dual-Channel DDR4-2400.

Detaillierte Informationen über die Raven Ridge APUs finden sie in unserem Launchartikel.

SerieAMD Raven Ridge (Ryzen 2000 APU)
CodenameZen
Serie: Raven Ridge (Ryzen 2000 APU) Zen
AMD Ryzen 5 2400G compare3.6 - 3.9 GHz4 / 84 MB
AMD Ryzen 7 2800H compare3.3 - 3.8 GHz4 / 84 MB
AMD Ryzen 7 2700U compare2.2 - 3.8 GHz4 / 84 MB
AMD Ryzen 7 PRO 2700U compare2.2 - 3.8 GHz4 / 84 MB
AMD Ryzen 3 2200G compare3.5 - 3.7 GHz4 / 44 MB
AMD Ryzen 5 2600H compare3.2 - 3.6 GHz4 / 84 MB
AMD Ryzen 5 2500U compare2 - 3.6 GHz4 / 84 MB
AMD Ryzen 5 PRO 2500U compare2 - 3.6 GHz4 / 84 MB
» AMD Ryzen Embedded V1605B2 - 3.6 GHz4 / 84 MB
AMD Ryzen 3 2300U compare2 - 3.4 GHz4 / 44 MB
AMD Ryzen 3 PRO 2300U compare2 - 3.4 GHz4 / 44 MB
AMD Ryzen 3 2200U compare2.5 - 3.4 GHz2 / 44 MB
AMD Ryzen 3 PRO 2200U compare2.5 - 3.4 GHz2 / 44 MB
AMD Ryzen Embedded R1505G compare2.4 - 3.3 GHz2 / 44 MB
AMD Athlon 300U compare2.4 - 3.3 GHz2 / 44 MB
AMD Athlon Silver 3050e compare0 - 2.8 GHz2 / 44 MB
AMD 3020e compare1.2 - 2.6 GHz2 / 24 MB
AMD 3015e compare1.2 - 2.3 GHz2 / 44 MB
Taktung2000 - 3600 MHz
Level 1 Cache384 KB
Level 2 Cache2 MB
Level 3 Cache4 MB
Anzahl von Kernen / Threads4 / 8
Stromverbrauch (TDP = Thermal Design Power)15 Watt
Transistoren4500 Millionen
Herstellungstechnologie14 nm
Max. Temperatur105 °C
SocketAM4
FeaturesXFR, FMA3, SSE 4.2, AVX2, SMT
GPUAMD Radeon RX Vega 8 (Ryzen 2000/3000) ( - 1100 MHz)
64 Bit64 Bit wird unterstützt
Architecturex86
Vorgestellt am21.02.2018
Produktinformationen beim HerstellerAMD Raven Ridge (Ryzen 2000 APU) Ryzen V1605B

Benchmarks

Performance Rating - CB R15 + R20 + 7-Zip + X265 + Blender + 3DM11 CPU
35.9 pt (36%)
Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
654 Points (15%)
03570105140175210245280315350385420455490525560595630653.74653.07645.17646.15624.13647.04645.89645.9643.96643.29641.68640.88636.9640.08640.07639.13637.7637.51638.66637.86636.73635.8635.48635.49635.17633.58634.22633.59631.86632.65632.8632.34630.93630.93629.05628.61629.68630.01628.91628.75627.69628.92627.83628.61626.91628.14627.68625.69626.92626.14Tooltip
HWBOT x265 Benchmark v2.2 - HWBOT x265 4k Preset
3.6 fps (11%)
0123456780.632.63.684.225.165.675.826.46.696.626.977.027.177.467.387.637.547.667.837.747.957.957.968.068.058.018.038.128.068.148.198.198.067.867.787.567.517.437.27.247.046.987.016.816.846.776.66.496.516.476.416.36.326.276.246.156.16.136.066.036.096.056.16.136.136.056.035.955.955.95.935.915.845.855.815.795.735.725.735.685.625.655.615.545.55.395.345.375.365.315.345.35.265.255.235.245.235.155.185.165.155.15.085.095.085.025.035.024.974.984.964.94.914.894.844.854.834.814.794.764.744.744.734.724.684.694.694.664.644.624.634.614.64.554.574.544.54.494.494.484.464.454.464.454.444.414.394.374.374.384.354.324.334.334.34.284.284.274.274.264.234.244.234.194.24.24.164.184.144.154.144.124.114.114.094.14.094.064.074.074.054.034.024.034.024.023.99443.983.973.973.973.973.963.943.953.943.933.923.933.923.913.923.93.923.913.93.93.913.93.93.893.93.93.893.883.93.883.883.873.873.883.883.863.883.873.853.863.863.853.873.873.863.863.873.863.873.873.863.883.873.873.883.893.893.893.93.93.913.923.943.953.973.983.9944.014.024.0144.014.014.014444.0143.99443.993.993.993.993.983.983.973.983.983.973.973.963.973.963.963.953.933.943.933.933.923.933.933.923.923.923.923.913.923.93.913.913.93.93.93.93.93.893.93.893.893.883.883.893.883.883.873.883.883.883.873.883.873.863.873.863.873.863.863.873.863.863.863.853.863.853.853.853.853.853.853.853.843.853.843.843.833.833.833.833.833.823.823.823.813.813.813.83.813.83.83.83.793.793.83.83.793.783.793.793.783.783.783.783.773.783.773.783.773.773.773.773.773.773.763.773.773.773.763.763.773.773.773.773.763.753.763.753.743.753.753.743.743.743.743.743.743.733.723.733.723.713.713.73.73.73.73.693.693.693.683.673.673.673.663.663.653.653.653.653.643.643.633.633.623.623.623.623.63.593.63.63.593.593.583.583.573.573.553.553.553.543.543.543.543.543.543.543.543.543.543.543.543.553.563.573.573.583.593.63.613.623.623.633.643.653.663.663.673.673.683.693.693.693.693.693.73.693.693.693.693.693.693.693.693.683.693.693.693.693.693.693.683.693.683.693.693.683.683.683.683.683.683.683.683.683.683.683.683.683.683.673.683.673.673.673.673.673.673.673.663.673.663.663.663.663.663.663.663.653.663.663.653.653.653.653.653.653.643.653.653.643.643.643.643.643.643.633.643.633.633.633.633.623.623.613.613.613.613.593.63.63.593.593.593.593.593.583.593.593.583.573.583.573.573.573.573.573.573.573.563.563.563.563.563.553.563.563.553.553.553.553.543.543.543.543.543.543.533.533.533.533.533.523.533.523.523.523.523.523.523.523.523.523.523.523.523.523.513.513.513.513.513.513.53.513.513.53.53.53.53.53.493.493.493.483.483.473.473.473.473.473.463.463.463.463.463.463.463.453.453.453.443.443.443.443.443.443.433.443.443.433.423.433.423.423.423.433.423.423.423.423.423.423.413.413.413.413.413.413.413.413.413.413.43.43.43.393.393.393.393.383.383.383.383.383.383.373.373.373.363.363.363.363.363.353.353.353.353.353.353.353.343.343.343.343.343.343.343.333.343.333.333.333.333.323.323.323.323.323.313.313.313.313.313.313.313.313.313.33.33.33.33.293.33.293.293.293.293.33.33.313.313.313.323.323.333.333.343.343.343.353.353.363.363.363.373.373.373.383.383.383.393.393.393.43.43.43.413.413.413.423.423.423.433.433.433.443.443.443.453.453.453.463.463.463.463.473.473.473.483.483.493.493.493.493.53.53.53.53.513.513.513.513.513.513.523.523.523.523.533.533.533.543.543.553.553.553.563.563.563.563.573.573.573.573.573.583.583.583.593.593.593.63.63.63.63.613.613.623.623.633.633.64Tooltip
- Bereich der Benchmarkergebnisse für diese Grafikkarte
- Durchschnittliche Benchmarkergebnisse für diese Grafikkarte
* Smaller numbers mean a higher performance

Ein oder mehrere Geräte zum Vergleich auswählen

In der folgenden Liste können sie Geräte suchen und für einen Vergleich auswählen.

Liste einschränken:

show all (including archived), 2021, 2020
v1.16
log 16. 15:43:31

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Tue, 15 Jun 2021 11:54:11 +0200 +0.001s ... 0.001s

#3 composed specs +0.008s ... 0.008s

#4 did output specs +0s ... 0.008s

#5 getting avg benchmarks for device 13197 +0.005s ... 0.014s

#6 got single benchmarks 13197 +0.007s ... 0.02s

#7 got avg benchmarks for devices +0s ... 0.02s

#8 min, max, avg, median took s +0.181s ... 0.201s

#9 return log +0.028s ... 0.23s

:: Noch keine Testberichte für diese CPU gefunden.
