Intel Core i5-520UM

Intel 520UM

Der Intel Core i5-520UM ist ein zwei-Kern Prozessor für sehr kleine und leichte Notebooks und taktet dank Turbo mit 1.06 - 1.86 GHz. Das U im Namen steht für Ultra Low Voltage und bezeichnet den geringen Stromverbrauch der CPU (sie wird mit einer geringen Spannung betrieben). Die zwei Kerne basiert auf die Nehalem (Westmere) Mikro-Architektur und können dank Hyperthreading 4 Threads gleichzeitig abarbeiten. Der langsamere Turbo und der geringer L3 Cache sind der Unterschied zum i7-620UM.

Eine Besonderheit der neuen Dual-Core CPUs von Intel ist die Integration des Speichercontrollers und einer integrierten Grafikkarte (GMA HD) in das Package. Die CPU wird bereits in 32nm hergestellt, der Die für den Speichercontroller und die Grafikkarte jedoch noch in 45nm.

Im Vergleich zu den anderen Dual Core Core i5 CPUs, bieten die U Modelle nur Anschluss für DDR3 800.

Erster Performance Test des Desktop Core i3 530 (2.93 GHz ohne Turbo) bescheinigt eine teilweise spürbar bessere Performance der neuen Architektur im Vergleich zu einem Core 2 Duo E8400 (3.0 GHz) [pconline.com.cn]. Dadurch sollte der Core i5-520UM im Schnitt schneller als ein Core 2 Duo SU9400 (1.4 GHz) sein. Je nachdem wie gut das Kühlungssystem des Subnotebooks ist, kann auch der Turbo oft greifen und dadurch die Geschwindigkeit noch deutlich erhöhen.

Die 32-nm-Prozessorkerne der Westmere-Generation verarbeiten auch einige neue Befehle, die AES-Verschlüsselung beschleunigen sollen.

Die integrierte Intel Graphics Media Accelerator HD (GMA HD) Grafikkarte wird mit 133-500 MHz getaktet werden (dank Turbo Boost) und schneller sein als die alte GMA 4500MHD.

Der Stromverbrauch ist mit einem TDP von 17 Watt zwar relativ hoch für einen ULV Prozessor, jedoch ist darin die integrierte Grafikkarte und auch der Speichercontroller enthalten (vormals im Chipsatz welcher selbst 12 Watt benötigte). Dadurch ist der Stromverbrauch des ganzen Systems relativ gering. Durch den Turbo Mode wird der TDP unter Last jedoch (öfter) ausgereizt, wodurch der Stromverbrauch höher ausfallen kann als bei ähnlich spezifizierten Core 2 Duo Modellen.

SerieIntel Core i5
CodenameArrandale

Serie: Core i5 Arrandale

Intel Core i5-580M compare2.67 - 3.33 GHz2 / 4 cores3 MB L3
Intel Core i5-560M compare2.67 - 3.2 GHz2 / 4 cores3 MB L3
Intel Core i5-480M compare2.67 - 2.93 GHz2 / 4 cores3 MB L3
Intel Core i5-540M compare2.53 - 3.07 GHz2 / 4 cores3 MB L3
Intel Core i5-460M compare2.53 - 2.8 GHz2 / 4 cores3 MB L3
Intel Core i5-520M compare2.4 - 2.93 GHz2 / 4 cores3 MB L3
Intel Core i5-450M compare2.4 - 2.66 GHz2 / 4 cores3 MB L3
Intel Core i5-430M compare2.26 - 2.53 GHz2 / 4 cores3 MB L3
Intel Core i5-560UM compare1.33 - 2.13 GHz2 / 4 cores3 MB L3
Intel Core i5-470UM compare1.33 - 1.87 GHz2 / 4 cores3 MB L3
Intel Core i5-540UM compare1.2 - 2 GHz2 / 4 cores3 MB L3
Intel Core i5-520UM « 1.06 - 1.87 GHz2 / 4 cores3 MB L3
Intel Core i5-430UM compare1.2 - 1.73 GHz2 / 4 cores3 MB L3
Taktung1060 - 1866 MHz
Front Side Bus2500
Level 2 Cache512 KB
Level 3 Cache3 MB
Anzahl von Kernen / Threads2 / 4
Stromverbrauch (TDP = Thermal Design Power)18 Watt
Transistoren382+177 Millionen
Herstellungstechnologie32 nm
Die Größe81+114 mm2
Max. Temperatur105 °C
SocketBGA1288
FeaturesTurbo Boost (1.86 GHz max), Hyper Threading, Enhanced Speedstep, integrierte GMA HD 166-500MHz,
64 Bit64 Bit wird unterstützt
Architecturex86
Anfangspreis$241 U.S.
Vorgestellt am04.01.2010
Produktinformationen beim Herstellerark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 1.02     avg: 1.2     median: 1.2 (2%)     max: 1.33 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 1471     avg: 1981     median: 1942.5 (12%)     max: 2569 Punkte
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 2785     avg: 3670     median: 3778 (3%)     max: 4340 Punkte
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 3946     avg: 4600     median: 4632.5 (3%)     max: 5187 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 2263     avg: 2561     median: 2423.5 (3%)     max: 3135 Points
3DMark 06 - CPU - 3DMark 06 - CPU
min: 982     avg: 1429     median: 1492 (3%)     max: 1718 Points
PCMark 05 - PCMark 05 - Standard
min: 2848     avg: 3571     median: 3925 (8%)     max: 3940 Points
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 3751     avg: 4065     median: 4064.5 (4%)     max: 4378 Points
- Bereich der Benchmarkergebnisse für diese Grafikkarte
- Durchschnittliche Benchmarkergebnisse für diese Grafikkarte
* Smaller numbers mean a higher performance
