Intel Core i5-2537M

Intel 2537M

Der Intel Core i5-2537M ist ein stromsparender ULV (Ultra Low Voltage) Prozessor für Subnotebooks. Mit 1.4 GHz Basistaktfrequenz ist er relativ gering getaktet, jedoch kann er dank Turbo Boost bis zu 2.3 GHz hochtakten (2 Ghz bei Belastung beider Kerne). Durch die Unterstützung von Hyperthreading können 4 Threads gleichzeitig bearbeitet werden.

Sandy Bridge ist eine Weiterentwicklung der Arrandale Architektur. Neben Optimierungen sind besonders die neuen 256 Bit AVX Instruktionen im CPU Teil und der verbesserte Turbo 2.0 erwähnenswert. Weiters sind nun ebenfalls AES Funktionen und ein verbesserter Dual Channel DDR3 Speicherkontroller für max. 8 GB DDR3-1333MHz direkt im Prozessor integriert.

Die intergrierte DirectX 10 fähige Intel HD Graphics 3000 Grafikkarte ist direkt in der CPU untergebracht und teilt sich mit dieser den Level 3 / Last Level Cache. Dadurch sinkt zwar die Prozessorleistung etwas bei aktivierter Grafik, die Grafikleistung ist jedoch deutlich besser als bei der alten Intel HD Graphics in ULV Notebooks. Vergleichen mit den stärkeren 35 Watt Doppelkernprozessoren ist die Grafikleistung jedoch aufgrund der geringeren Taktfrequenz deutlich schlechter (350 versus 650 MHz Basistakt, 900 versus 1100-1300 MHz Turbo Boost).

Die Performance liegt dank der verbesserten Architektur und des überarbeiteten Turbo Boost etwas oberhalb einer ähnlich getakteten Arrandale CPU. Dadurch sollte die Leistung auf dem Niveau des Core i7-680UM liegen und damit in der Nähe des Core i3-330M (falls der Turbo Boost dank ausreichend Kühlung gut funktioniert).

Die Sandy Bridge Doppelkernprozessoren beinhalten im angegebenen TDP von 17 Watt auch die Grafikkarte und den Speicherkontroller. Durch den Turbo Boost 2.0 wird der TDP jedoch unter Last eher ausgenutzt. Mit 17W TDP eignet sich der Prozessor auch für kleine und leichte Notebooks.

SerieIntel Core i5
CodenameSandy Bridge

Serie: Core i5 Sandy Bridge

Intel Core i5-2540M compare2.6 - 3.3 GHz2 / 4 cores3 MB L3
Intel Core i5-2520M compare2.5 - 3.2 GHz2 / 4 cores3 MB L3
Intel Core i5-2450M compare2.5 - 3.1 GHz2 / 4 cores3 MB L3
Intel Core i5-2435M compare2.4 - 3 GHz2 / 4 cores3 MB L3
Intel Core i5-2430M compare2.4 - 3 GHz2 / 4 cores3 MB L3
Intel Core i5-2415M compare2.3 - 2.9 GHz2 / 4 cores3 MB L3
Intel Core i5-2410M compare2.3 - 2.9 GHz2 / 4 cores3 MB L3
Intel Core i5-2557M compare1.7 - 2.7 GHz2 / 4 cores3 MB L3
Intel Core i5-2467M compare1.6 - 2.3 GHz2 / 4 cores3 MB L3
Intel Core i5-2537M « 1.4 - 2.3 GHz2 / 4 cores3 MB L3
Taktung1400 - 2300 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache3 MB
Anzahl von Kernen / Threads2 / 4
Stromverbrauch (TDP = Thermal Design Power)17 Watt
Transistoren624 Millionen
Herstellungstechnologie32 nm
Die Größe149 mm2
Max. Temperatur100 °C
SocketBGA1023
FeaturesHD Graphics 3000 (350-900MHz), DDR3-1066/1333 Memory Controller (max 8GB), HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 3000 (350 - 900 MHz)
64 Bit64 Bit wird unterstützt
Architecturex86
Anfangspreis$250 U.S.
Vorgestellt am03.01.2011
Produktinformationen beim Herstellerark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 1.41     avg: 1.7     median: 1.7 (2%)     max: 1.93 Points
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 4157     avg: 5330     median: 5903 (4%)     max: 5929 Punkte
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 5127     avg: 6201     median: 6200.5 (4%)     max: 7274 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 3577     avg: 3609     median: 3608.5 (4%)     max: 3640 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 792     avg: 975     median: 975 (12%)     max: 1158 s
wPrime 2.10 - wPrime 2.0 32m *
min: 24.8     avg: 24.9     median: 24.9 (5%)     max: 25 s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 1696     avg: 2182     median: 2400 (5%)     max: 2451 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 17     avg: 17.2     median: 17.2 (4%)     max: 17.33 s
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
23500 MFLOPS (18%)
- Bereich der Benchmarkergebnisse für diese Grafikkarte
- Durchschnittliche Benchmarkergebnisse für diese Grafikkarte
* Smaller numbers mean a higher performance
