Intel Core i7-940XM

Intel 940XM

Der Intel Core i7 940XM Extreme Edition ist ein High-End Notebook Prozessor und Nachfolger des 920XM Quad Cores. Er bietet 4 Kerne (Quad Core CPU) welche, je nach Auslastung und Kühlung, mit 2.13 - 3.3 GHz getaktet werden (Turbo Boost). Bei Auslastung aller 4 Kerne können max. 2.4 GHz, bei Auslastung von zwei Kerne 3.2 GHz und bei nur einem Kern die maximalen 3.3 GHz erreicht werden. Dank Hyperthreading können bis zu 8 Threads gleichzeitig bearbeitet werden (zur besseren Auslastung der Prozessor-Pipeline).

Der 940XM hat einen integrierten Speichercontroller, welcher DDR3 1066 und 1333 Speicher direkt ansprechen kann.

Dank Turbo Boost, ist die Performance des 940XM meistens Vergleichbar mit dem Desktop Core i7-750 Quad Core. Dadurch ist die Performance für alle anspruchsvollen Spiele und Anwendungen von 2010 ausreichend. In Extremfällen kann jedoch die Performance etwas einbrechen, da der "Minimaltakt" von 2,13 GHz nicht sonderlich hoch ist.

Der Stromverbrauch ist mit 55 Watt TDP (Maximum) sehr hoch (jedoch inkl. eingebautem Speichercontroller). Daher eignet sich der Core i7-940XM nur für große Laptops mit ausreichendem Kühlsystem.

Die CPU gehört zur Extreme Serie von Intel CPUs und lässt sich daher dank frei wählbarem Multiplikator sehr einfach übertakten.

SerieIntel Core i7
CodenameClarksfield

Serie: Core i7 Clarksfield

Intel Core i7-940XM « 2.13 - 3.33 GHz4 / 8 cores8 MB L3
Intel Core i7-920XM compare2 - 3.2 GHz4 / 8 cores8 MB L3
Intel Core i7-840QM compare1.86 - 3.2 GHz4 / 8 cores8 MB L3
Intel Core i7-820QM compare1.73 - 3.06 GHz4 / 8 cores8 MB L3
Intel Core i7-740QM compare1.73 - 2.93 GHz4 / 8 cores6 MB L3
Intel Core i7-720QM compare1.6 - 2.8 GHz4 / 8 cores6 MB L3
Taktung2130 - 3333 MHz
Front Side Bus2500
Level 1 Cache256 KB
Level 2 Cache1 MB
Level 3 Cache8 MB
Anzahl von Kernen / Threads4 / 8
Stromverbrauch (TDP = Thermal Design Power)55 Watt
Transistoren774 Millionen
Herstellungstechnologie45 nm
Die Größe296 mm2
Max. Temperatur100 °C
SocketRPGA989
Features2.5 GT/s DMI, Virtualization Technology, Execute Disable Bit, Enahnced Speedstep Technology, Enhanced Halt State (C1E), 64, Turbo Boost (max. 3.33 GHz), Hyper-Threading, Trusted Execution Technology
64 Bit64 Bit wird unterstützt
Architecturex86
Anfangspreis$1096 U.S.
Vorgestellt am01.06.2010
Produktinformationen beim Herstellerark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 3.65     avg: 3.9     median: 3.9 (5%)     max: 4.05 Points
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
11391 Punkte (8%)
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 12642     avg: 13381     median: 13381 (9%)     max: 14120 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 4479     avg: 4488     median: 4488 (5%)     max: 4497 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 374     avg: 798     median: 798 (9%)     max: 1222 s
wPrime 2.10 - wPrime 2.0 32m *
min: 12     avg: 25.2     median: 25.2 (5%)     max: 38.36 s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 3884     avg: 4080     median: 4064 (9%)     max: 4293 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
12 s (3%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 699     avg: 700     median: 700 (3%)     max: 701 s
- Bereich der Benchmarkergebnisse für diese Grafikkarte
- Durchschnittliche Benchmarkergebnisse für diese Grafikkarte
* Smaller numbers mean a higher performance
