Intel Core i5-2540M

Intel 2540M

Der Intel Core i5-2540M ist ein schneller High-End Doppelkernprozessor für Notebooks welcher Anfang 2011 vorgestellt wurde. Er bietet zwei Kerne und kann dank Hyperthreading 4 Threads gleichzeitig bearbeiten. Der Basistakt von 2,6 GHz kann durch Turbo Boost bei ausreichender Kühlung auf 3,1 GHz (Belastung von 2 Kernen) und 3,3 (1 Kern) dynamisch gesteigert werden. Im Vergleich zum schnelleren i7-2620M, bietet der 2540M nicht nur eine geringere Taktrate, sondern auch weniger Last Level Cache (3 versus 4MB).

Sandy Bridge ist eine Weiterentwicklung der Arrandale Architektur. Neben Optimierungen sind besonders die neuen 256 Bit AVX Instruktionen im CPU Teil und der verbesserte Turbo 2.0 erwähnenswert. Weiters sind nun ebenfalls AES Funktionen und ein verbesserter Dual Channel DDR3 Speicherkontroller für max. 8 GB DDR3-1333MHz direkt im Prozessor integriert.

Die intergrierte DirectX 10 fähige Intel HD Graphics 3000 Grafikkarte ist direkt in der CPU untergebracht und teilt sich mit dieser den Level 3 / Last Level Cache. Dadurch sinkt zwar die Prozessorleistung etwas bei aktivierter Grafik, die Grafikleistung ist jedoch deutlich besser als bei der alten Intel HD Graphics und auf Niveau einer Nvidia Geforce 310M Einstiegsgrafikkarte.  Dank Turbo Boost wird sie von 650MHz bis 1300MHz getaktet.

Die Performance liegt dank der verbesserten Architektur  und des überarbeiteten Turbo Boost etwas oberhalb einer ähnlich getakteten Arrandale CPU. Dadurch sollte der i5-2540M in etwa auf dem Niveau des alten Core i7-620M liegen. Daher reicht die Leistung auch für anspruchsvolle Tätigkeiten wie HD Videoschnitt oder 3D Spiele. Durch die hohe Taktrate von 2.6 GHz (3.1 - 3.3 GHz mittels Turbo) hat der 2540M auch Vorteile gegenüber den langsamer getakteten Quad-Core Prozessoren bei Software die nur 1-2 Threads auslastet.

Die Sandy Bridge Doppelkernprozessoren beinhalten im angegebenen TDP von 35 Watt auch die Grafikkarte und den Speicherkontroller. Durch den Turbo Boost 2.0 wird der TDP jedoch unter Last durchaus ausgenutzt. Mit 35W TDP eignet sich der Prozessor am besten für 14" Notebooks und größer.

SerieIntel Core i5
CodenameSandy Bridge

Serie: Core i5 Sandy Bridge

Intel Core i5-2540M « 2.6 - 3.3 GHz2 / 4 cores3 MB L3
Intel Core i5-2520M compare2.5 - 3.2 GHz2 / 4 cores3 MB L3
Intel Core i5-2450M compare2.5 - 3.1 GHz2 / 4 cores3 MB L3
Intel Core i5-2435M compare2.4 - 3 GHz2 / 4 cores3 MB L3
Intel Core i5-2430M compare2.4 - 3 GHz2 / 4 cores3 MB L3
Intel Core i5-2415M compare2.3 - 2.9 GHz2 / 4 cores3 MB L3
Intel Core i5-2410M compare2.3 - 2.9 GHz2 / 4 cores3 MB L3
Intel Core i5-2557M compare1.7 - 2.7 GHz2 / 4 cores3 MB L3
Intel Core i5-2467M compare1.6 - 2.3 GHz2 / 4 cores3 MB L3
Intel Core i5-2537M compare1.4 - 2.3 GHz2 / 4 cores3 MB L3
Taktung2600 - 3300 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache3 MB
Anzahl von Kernen / Threads2 / 4
Stromverbrauch (TDP = Thermal Design Power)35 Watt
Transistoren624 Millionen
Herstellungstechnologie32 nm
Die Größe149 mm2
Max. Temperatur100 °C
SocketrPGA988B, BGA1023
FeaturesHD Graphics 3000 (650-1300MHz), DDR3-1066/1333 Memory Controller (max 8GB), HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 3000 (650 - 1300 MHz)
64 Bit64 Bit wird unterstützt
Architecturex86
Anfangspreis$266 U.S.
Vorgestellt am20.02.2011
Produktinformationen beim Herstellerark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 2.77     avg: 2.9     median: 3 (4%)     max: 2.98 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 3923     avg: 4135     median: 4171 (25%)     max: 4234 Punkte
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 8386     avg: 8998     median: 9109 (7%)     max: 9259 Punkte
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 10077     avg: 10797     median: 10935.5 (8%)     max: 11242 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 4816     avg: 5105     median: 5194 (6%)     max: 5276 Points
3DMark 06 - CPU - 3DMark 06 - CPU
min: 3334     avg: 3632     median: 3682 (8%)     max: 3701 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 12     avg: 12.2     median: 12 (3%)     max: 13 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 27     avg: 28.6     median: 28.3 (1%)     max: 30 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 644     avg: 668     median: 663 (3%)     max: 699 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 48900     avg: 53760     median: 51870 (25%)     max: 60510 MIPS
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 34400     avg: 36297     median: 36840 (28%)     max: 37650 MFLOPS
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 9338     avg: 9775     median: 9869.5 (9%)     max: 10023 Points
3DMark 11 - 3DM11 Performance Physics
min: 3439     avg: 3646     median: 3654 (10%)     max: 3836 Points
- Bereich der Benchmarkergebnisse für diese Grafikkarte
- Durchschnittliche Benchmarkergebnisse für diese Grafikkarte
* Smaller numbers mean a higher performance
