Intel UHD Graphics 770 vs Intel UHD Graphics 750

Intel UHD Graphics 770

Intel UHD Graphics 770

Die Intel UHD Graphics 770 ist eine integrierte Grafikkarte (iGPU) in Alder Lake und Raptor Lake Prozessoren (12. und 13. Generation, GT1). Sie nutzt die Intel Xe Architektur und bietet 32 Execution Units (EUs, Kerne - gesamt 256 Shader) die in den HX-Chips und Desktop Chips integriert sind. Die maximale Taktung ist 1,55 GHz und die GPU besitzt keinen eigenen Grafikspeicher.

Dank der hohen Taktung und der meist starken CPU, ist die Gaming Performance besser als bei den kleineren Tiger Lake Modellen mit 32 EUs. Dadurch sind auch einige aktuelle Spiele in minimalen Settings und 720p flüssig spielbar. Anspruchsvollere Spiele wie Dying Light 2 oder Cyberpunk 2077 laufen jedoch nicht flüssig (siehe unten).

Die UHD Graphics unterstützt bis zu 4 Displays gleichzeitig (wenn genügend Ports verbaut werden) und eDP 1.4b, DisplayPort 1.4a und HDMI 2.1. Die maximale unterstützte Auflösung ist je nach Port unterschiedlich: 5k120Hz (per eDP) bzw 8k60 (DP) und 4k60 (HDMI).

Der SoC (wie z.B. i9-12900HX) wird im Intel 7 Prozess (verbesserter 10nm Prozess) gefertigt.

Intel UHD Graphics 750

► remove from comparison

Intel UHD Graphics 770Intel UHD Graphics 750
Gen. 12 / xG Serie
UHD Graphics 770 32/ cores @ 0.3 - 1.55 GHz
UHD Graphics 750
UHD Graphics 770 32/ cores @ 0.3 - 1.55 GHz
UHD Graphics 750
CodenameAlder Lake xGAlder Lake xG
ArchitekturAlder Lake
Pipelines32 / Pixel- / Vertexshader
TMUs16
ROPs8
Kerntakt300 - 1550 (Boost) MHz
Shared Memoryneinnein
Stromverbrauch15 Watt
Herstellungsprozess10 nm
Erscheinungsdatum04.01.2022
CPU in UHD Graphics 770GPU Base SpeedGPU Boost / Turbo
Intel Core i9-14900K24 x 3200 MHz, 125 W300 MHz1650 MHz
Intel Core i9-13900K24 x 3000 MHz, 125 W300 MHz1650 MHz
Intel Core i7-14700K20 x 2500 MHz, 125 W300 MHz1600 MHz
min. - max.? - 300 MHz1350 - 1650 MHz
CPU in UHD Graphics 750GPU Base SpeedGPU Boost / Turbo
Intel Core i7-117008 x 2500 MHz, 65 W350 MHz1300 MHz

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy - UHD Graphics 770
1.3 pt (4%)
3DMark - 3DMark Time Spy Score
min: 923     avg: 927     median: 926.5 (3%)     max: 930 Points
3DMark - 3DMark Time Spy Graphics
min: 793     avg: 796     median: 795.5 (2%)     max: 798 Points
3DMark - 3DMark Ice Storm Unlimited Graphics
179804 Points (20%)
3DMark - 3DMark Ice Storm Extreme Graphics
46258 Points (6%)
3DMark - 3DMark Cloud Gate Score
17404 Points (19%)
3DMark - 3DMark Cloud Gate Graphics
16443 Points (4%)
3DMark - 3DMark Fire Strike Standard Score
min: 2686     avg: 2738     median: 2738 (5%)     max: 2790 Points
3DMark - 3DMark Fire Strike Standard Graphics
min: 2768     avg: 2834     median: 2834 (3%)     max: 2900 Points
3DMark - 3DMark Ice Storm Graphics
58760 Points (7%)
3DMark - 3DMark Wild Life Unlimited
7086 Points (4%)
3DMark - 3DMark Wild Life Extreme Unlimited
1891 Points (2%)
3DMark - 3DMark Night Raid
12747 Points (12%)
3DMark - 3DMark Night Raid Graphics Score
12097 Points (5%)
3DMark 11 - 3DM11 Performance Score
min: 4133     avg: 4157     median: 4157 (6%)     max: 4181 Points
3DMark 11 - 3DM11 Performance GPU
min: 3535     avg: 3563     median: 3563 (3%)     max: 3591 Points
3DMark Vantage
3DM Vant. Perf. total + Intel UHD Graphics 770
3DMark Vantage - 3DM Vant. Perf. total
15865 Points (5%)
3DM Vant. Perf. GPU no PhysX + Intel UHD Graphics 770
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
12456 Points (7%)
3DMark 06 3DMark 06 - Standard 1280x1024 + Intel UHD Graphics 770
3DMark 06
23428 Points (31%)
Unigine Valley 1.0 - Unigine Valley 1.0 DX
11 fps (4%)
Unigine Heaven 3.0 - Unigine Heaven 3.0 DX 11
34.9 fps (12%)
Unigine Heaven 3.0 - Unigine Heaven 3.0 OpenGL
38.5 fps (17%)
Unigine Heaven 2.1 - Heaven 2.1 high
48.3 fps (9%)
Cinebench R15
Cinebench R15 OpenGL 64 Bit + Intel UHD Graphics 770
Cinebench R15 - Cinebench R15 OpenGL 64 Bit
94.6 fps (6%)
Cinebench R15 OpenGL Ref. Match 64 Bit + Intel UHD Graphics 770
Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
97.8 % (98%)
GFXBench - GFXBench 5.0 4K Aztec Ruins High Tier Offscreen
11.1 fps (5%)
GFXBench - GFXBench 5.0 Aztec Ruins High Tier Offscreen
27 fps (5%)
GFXBench - GFXBench 5.0 Aztec Ruins Normal Tier Offscreen
76.8 fps (6%)
GFXBench - GFXBench Car Chase Offscreen
65 fps (7%)
GFXBench 3.1 - GFXBench Manhattan ES 3.1 Offscreen
86.4 fps (2%)
GFXBench 3.0 - GFXBench 3.0 Manhattan Offscreen
161.8 fps (9%)
GFXBench (DX / GLBenchmark) 2.7
GFXBench T-Rex HD Offscreen C24Z16 + Intel UHD Graphics 770
GFXBench (DX / GLBenchmark) 2.7 - GFXBench T-Rex HD Offscreen C24Z16
236.1 fps (2%)
Basemark GPU 1.2 - Basemark GPU 1.2 Vulkan Official Medium Offscreen 1080
118.7 fps (1%)
Basemark GPU 1.2 - Basemark GPU 1.2 Vulkan Official High Offscreen 2160
3.6 fps (1%)
Geekbench 6.2 - Geekbench 6.2 GPU OpenCL
8346 Points (2%)
Geekbench 6.2 - Geekbench 6.2 GPU Vulkan
8934 Points (3%)
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
663 Samples/s (3%)
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
1293 Samples/s (2%)
ComputeMark v2.1 - ComputeMark v2.1 Result
1667 Points (2%)
Power Consumption - Furmark Stress Test Power Consumption - external Monitor *
40.1 Watt (6%)
Power Consumption - The Witcher 3 Power Consumption - external Monitor *
77.1 Watt (11%)
Power Consumption - Witcher 3 Power Consumption *
77.1 Watt (17%)
Emissions Witcher 3 Fan Noise + Intel UHD Graphics 770
Emissions - Witcher 3 Fan Noise
42.6 dB(A) (68%)

Average Benchmarks Intel UHD Graphics 770 → 0% n=

- Bereich der Benchmarkergebnisse für diese Grafikkarte
- Durchschnittliche Benchmarkergebnisse für diese Grafikkarte
* Smaller numbers mean a higher performance
1 This benchmark is not used for the average calculation

Spiele-Benchmarks

Die folgenden Benchmarks basieren auf unseren Spieletests mit Testnotebooks. Die Performance dieser Grafikkarte bei den gelisteten Spielen ist abhängig von der verwendeten CPU, Speicherausstattung, Treiber und auch Betriebssystem. Dadurch müssen die untenstehenden Werte nicht repräsentativ sein. Detaillierte Informationen über das verwendete System sehen Sie nach einem Klick auf den fps-Wert.

low 1920x1080
100%
UHD Graphics 770:
11  fps
F1 23

F1 23

2023
low 1920x1080
100%
UHD Graphics 770:
22.9  fps
med. 1920x1080
100%
UHD Graphics 770:
20.6  fps
high 1920x1080
100%
UHD Graphics 770:
13.8  fps
low 1920x1080
100%
UHD Graphics 770:
7.1  fps
low 1920x1080
100%
UHD Graphics 770:
12.4  fps
low 1920x1080
100%
UHD Graphics 770:
9.6  fps
low 1920x1080
100%
UHD Graphics 770:
15.2  fps
med. 1920x1080
100%
UHD Graphics 770:
10.9  fps
low 1920x1080
100%
UHD Graphics 770:
11.1  fps
low 1920x1080
100%
UHD Graphics 770:
7.8 (!)  fps
low 1920x1080
100%
UHD Graphics 770:
21.3  fps
med. 1920x1080
100%
UHD Graphics 770:
16.7  fps
low 1920x1080
100%
UHD Graphics 770:
20.5  fps
med. 1920x1080
100%
UHD Graphics 770:
12.7  fps
low 1920x1080
100%
UHD Graphics 770:
11.9  fps
med. 1920x1080
100%
UHD Graphics 770:
8.2  fps
low 1920x1080
100%
UHD Graphics 770:
13.2  fps
med. 1920x1080
100%
UHD Graphics 770:
11  fps
low 1920x1080
100%
UHD Graphics 770:
14.3 (!)  fps
low 1920x1080
100%
UHD Graphics 770:
17  fps
med. 1920x1080
100%
UHD Graphics 770:
11  fps
low 1920x1080
100%
UHD Graphics 770:
7.2  fps
low 1920x1080
100%
UHD Graphics 770:
8.8  fps
low 1920x1080
100%
UHD Graphics 770:
8.1  fps
F1 22

F1 22

2022
low 1920x1080
100%
UHD Graphics 770:
26.7  fps
med. 1920x1080
100%
UHD Graphics 770:
23.8  fps
high 1920x1080
100%
UHD Graphics 770:
17.1  fps
ultra 1920x1080
100%
UHD Graphics 770:
13  fps
low 1920x1080
100%
UHD Graphics 770:
16.4 17.2 ~ 17 fps
med. 1920x1080
100%
UHD Graphics 770:
13.7  fps
high 1920x1080
100%
UHD Graphics 770:
8.5  fps
low 1920x1080
100%
UHD Graphics 770:
10.2 11.8 ~ 11 fps
med. 1920x1080
100%
UHD Graphics 770:
9.7  fps
low 1920x1080
100%
UHD Graphics 770:
39.9  fps
med. 1920x1080
100%
UHD Graphics 770:
33.4  fps
high 1920x1080
100%
UHD Graphics 770:
28.1  fps
ultra 1920x1080
100%
UHD Graphics 770:
17.7  fps
low 1920x1080
100%
UHD Graphics 770:
20.6  fps
med. 1920x1080
100%
UHD Graphics 770:
19  fps
high 1920x1080
100%
UHD Graphics 770:
16  fps
low 1920x1080
100%
UHD Graphics 770:
11.3  fps
low 1920x1080
100%
UHD Graphics 770:
22  fps
med. 1920x1080
100%
UHD Graphics 770:
16  fps
high 1920x1080
100%
UHD Graphics 770:
16  fps
low 1280x720
100%
UHD Graphics 770:
33.9  fps
med. 1920x1080
100%
UHD Graphics 770:
15.7  fps
low 1280x720
100%
UHD Graphics 770:
43  fps
med. 1920x1080
100%
UHD Graphics 770:
18  fps
high 1920x1080
100%
UHD Graphics 770:
16  fps
low 1280x720
100%
UHD Graphics 770:
34.7  fps
med. 1920x1080
100%
UHD Graphics 770:
17.4  fps
high 1920x1080
100%
UHD Graphics 770:
13.4  fps
Far Cry 6

Far Cry 6

2021
low 1280x720
100%
UHD Graphics 770:
31.1  fps
med. 1920x1080
100%
UHD Graphics 770:
13.8  fps
high 1920x1080
100%
UHD Graphics 770:
11.2  fps
F1 2021

F1 2021

2021
low 1280x720
100%
UHD Graphics 770:
70.3  fps
med. 1920x1080
100%
UHD Graphics 770:
29.9  fps
high 1920x1080
100%
UHD Graphics 770:
24  fps
ultra 1920x1080
100%
UHD Graphics 770:
15.2  fps
low 1280x720
100%
UHD Graphics 770:
70.9  fps
ultra 1920x1080
100%
UHD Graphics 770:
33.6  fps
Hitman 3

Hitman 3

2021
low 1280x720
100%
UHD Graphics 770:
49  fps
med. 1920x1080
100%
UHD Graphics 770:
19  fps
high 1920x1080
100%
UHD Graphics 770:
15.7  fps
low 1280x720
100%
UHD Graphics 770:
26 (!)  fps
med. 1920x1080
100%
UHD Graphics 770:
13 (!)  fps
Dirt 5

Dirt 5

2020
low 1280x720
100%
UHD Graphics 770:
28.5  fps
med. 1920x1080
100%
UHD Graphics 770:
11.9  fps
high 1920x1080
100%
UHD Graphics 770:
9.7  fps
low 1280x720
100%
UHD Graphics 770:
51.4  fps
med. 1920x1080
100%
UHD Graphics 770:
23.3  fps
high 1920x1080
100%
UHD Graphics 770:
6.4  fps
low 1280x720
100%
UHD Graphics 770:
19.6  fps
low 1280x720
100%
UHD Graphics 770:
28  fps
med. 1920x1080
100%
UHD Graphics 770:
14  fps
high 1920x1080
100%
UHD Graphics 770:
11  fps
low 1280x720
100%
UHD Graphics 770:
27.3  fps
med. 1920x1080
100%
UHD Graphics 770:
15.6  fps
high 1920x1080
100%
UHD Graphics 770:
14.9  fps
ultra 1920x1080
100%
UHD Graphics 770:
14.3  fps
F1 2020

F1 2020

2020
low 1280x720
100%
UHD Graphics 770:
59.1  fps
med. 1920x1080
100%
UHD Graphics 770:
27.2  fps
high 1920x1080
100%
UHD Graphics 770:
20  fps
ultra 1920x1080
100%
UHD Graphics 770:
12.4  fps
low 1280x720
100%
UHD Graphics 770:
74.4  fps
med. 1920x1080
100%
UHD Graphics 770:
26.9  fps
high 1920x1080
100%
UHD Graphics 770:
16.9  fps
ultra 1920x1080
100%
UHD Graphics 770:
12.4  fps
low 1280x720
100%
UHD Graphics 770:
32.4  fps
med. 1920x1080
100%
UHD Graphics 770:
15.9  fps
high 1920x1080
100%
UHD Graphics 770:
14.5  fps
low 1280x720
100%
UHD Graphics 770:
40.7  fps
med. 1920x1080
100%
UHD Graphics 770:
16.1  fps
Control

Control

2019
low 1280x720
100%
UHD Graphics 770:
38.1  fps
med. 1920x1080
100%
UHD Graphics 770:
11  fps
low 1280x720
100%
UHD Graphics 770:
41  fps
med. 1920x1080
100%
UHD Graphics 770:
17  fps
low 1280x720
100%
UHD Graphics 770:
31.2  fps
med. 1920x1080
100%
UHD Graphics 770:
13.6  fps
Strange Brigade

Strange Brigade

2018
low 1280x720
100%
UHD Graphics 770:
66.1  fps
med. 1920x1080
100%
UHD Graphics 770:
27.5  fps
high 1920x1080
100%
UHD Graphics 770:
21.1  fps
ultra 1920x1080
100%
UHD Graphics 770:
17.2  fps
Far Cry 5

Far Cry 5

2018
low 1280x720
100%
UHD Graphics 770:
37  fps
med. 1920x1080
100%
UHD Graphics 770:
17  fps
high 1920x1080
100%
UHD Graphics 770:
16  fps
ultra 1920x1080
100%
UHD Graphics 770:
14  fps
low 1280x720
100%
UHD Graphics 770:
51.4 53.5 ~ 52 fps
med. 1920x1080
100%
UHD Graphics 770:
32.7 33.8 ~ 33 fps
high 1920x1080
100%
UHD Graphics 770:
29.7 30.7 ~ 30 fps
4K 3840x2160
100%
UHD Graphics 770:
12  fps
low 1280x720
100%
UHD Graphics 770:
27.2 28.2 ~ 28 fps
med. 1920x1080
100%
UHD Graphics 770:
14.6 14.6 ~ 15 fps
high 1920x1080
100%
UHD Graphics 770:
9.9 10.2 ~ 10 fps
low 1280x720
100%
UHD Graphics 770:
153.1 154.6 ~ 154 fps
med. 1366x768
100%
UHD Graphics 770:
95.4 96.1 ~ 96 fps
high 1920x1080
100%
UHD Graphics 770:
43 44.2 ~ 44 fps
ultra 1920x1080
100%
UHD Graphics 770:
40 40.8 ~ 40 fps
4K 3840x2160
100%
UHD Graphics 770:
14.2  fps
low 1024x768
100%
UHD Graphics 770:
54.1 58 ~ 56 fps
med. 1366x768
100%
UHD Graphics 770:
34.2 37.9 ~ 36 fps
high 1920x1080
100%
UHD Graphics 770:
17.5  fps
ultra 1920x1080
100%
UHD Graphics 770:
8.6  fps
GTA V

GTA V

2015
low 1024x768
100%
UHD Graphics 770:
125  fps
med. 1366x768
100%
UHD Graphics 770:
99.9  fps
high 1920x1080
100%
UHD Graphics 770:
16.1  fps
ultra 1920x1080
100%
UHD Graphics 770:
7  fps

Average Gaming Intel UHD Graphics 770 → 100%

Average Gaming 30-70 fps → 100%

Intel UHD Graphics 770lowmed.highultraQHD4K
Atlas Fallen11
F1 2322.920.613.8
The Last of Us7.1
Resident Evil 4 Remake12.4
Sons of the Forest9.64
Atomic Heart15.210.9
Hogwarts Legacy11.1
Dead Space Remake7.79
The Witcher 3 v4.0021.316.7
High On Life20.512.7
The Callisto Protocol11.98.2
Need for Speed Unbound13.211
Spider-Man Miles Morales14.3
Call of Duty Modern Warfare 2 20221711
Uncharted Legacy of Thieves Collection7.17
A Plague Tale Requiem8.79
The Quarry8.05
F1 2226.723.817.113
Tiny Tina's Wonderlands1713.78.5
Cyberpunk 2077 1.6119.7
GRID Legends39.933.428.117.7
Elden Ring20.61916
Dying Light 211.3
Rainbow Six Extraction221616
Battlefield 204233.915.7
Forza Horizon 5431816
Back 4 Blood34.717.413.4
Far Cry 631.113.811.2
F1 202170.329.92415.2
Mass Effect Legendary Edition70.933.6
Hitman 3491915.7
Assassin´s Creed Valhalla2613
Dirt 528.511.99.7
Crysis Remastered51.423.36.37
Flight Simulator 202019.6
Horizon Zero Dawn281411
Death Stranding27.315.614.914.3
F1 202059.127.22012.4
Gears Tactics74.426.916.912.4
Doom Eternal32.415.914.5
Hunt Showdown40.716.1
Control38.111
The Division 24117
Metro Exodus31.213.6
Strange Brigade66.127.521.117.2
Far Cry 537171614
X-Plane 11.1152333012
Final Fantasy XV Benchmark281510
Dota 2 Reborn15496444014.2
The Witcher 3563617.58.61
GTA V12599.916.16.96
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps
29
16
4
2
33
3
2
23
2

10
2




2


Eine Liste mit weiteren Spielen und allen Grafikkarten finden Sie auf unserer Seite: Welches Spiel ist mit welcher Grafikkarte spielbar?

Add one or more devices and compare

In the following list you can select (and also search for) devices that should be added to the comparison. You can select more than one device.

restrict list:

show all (including archived), 2024, 2023
v1.26
log 28. 20:33:30

#0 checking url part for id 10972 +0s ... 0s

#1 checking url part for id 11372 +0s ... 0s

#2 not redirecting to Ajax server +0s ... 0s

#3 did not recreate cache, as it is less than 5 days old! Created at Thu, 28 Mar 2024 05:37:00 +0100 +0.001s ... 0.001s

#4 composed specs +0.065s ... 0.066s

#5 did output specs +0s ... 0.066s

#6 start showIntegratedCPUs +0s ... 0.066s

#7 getting avg benchmarks for device 10972 +0.052s ... 0.118s

#8 got single benchmarks 10972 +0.015s ... 0.133s

#9 getting avg benchmarks for device 11372 +0.002s ... 0.135s

#10 got single benchmarks 11372 +0s ... 0.135s

#11 got avg benchmarks for devices +0s ... 0.135s

#12 min, max, avg, median took s +0.167s ... 0.302s

#13 before gaming benchmark output +0s ... 0.302s

#14 Got 142 rows for game benchmarks. +0.01s ... 0.312s

#15 composed SQL query for gamebenchmarks +0s ... 0.312s

#16 got data and put it in $dataArray +0.038s ... 0.35s

#17 benchmarks composed for output. +0.12s ... 0.47s

#18 calculated avg scores. +0s ... 0.47s

#19 return log +0.039s ... 0.509s

Teilen Sie diesen Artikel, um uns zu unterstützen. Jeder Link hilft!
> Notebook Test, Laptop Test und News > Benchmarks / Technik > Benchmarks / Technik > Grafikkarten Vergleich - Head 2 Head
Autor: Klaus Hinum,  8.09.2017 (Update:  1.07.2023)
