Intel UHD Graphics 24EUs (Alder Lake-N)
Die Intel UHD Graphics 24 EUs (Xe-LP, Alder Lake-N, Gen 12.2) ist eine Prozessorgrafikkarte in Alder Lake-N CPU, welche in 2022 vorgestellt wurden. Sie basiert auf die neue Xe Architektur (Gen12) und bietet eine deutlich höhere Leistung als die Vorgängergenerationen. Die Leistung ist abhängig von der Taktrate (je nach Prozessormodell) und dem verwendeten Hauptspeicher (da shared Memory). Die 24 EU-Variante (Execution Units) bietet nur 24 der 32 EUs (192 der 256 Shader).
Durch die geringe CPU-Leistung, fehlenden dedizierten Speicher, single Channel-Spiecherkanal und die geringe Anzahl an Shader, ist die Spieleleistung der UHD Graphics in Alder Lake-N deutlich eingeschränkt. Dadurch sind nur wenige aktuelle Spiele flüssig spielbar.
Die GPU unterstützt maximal drei Displays mit einer maximalen Auflösung von 4096x2160 bei 60Hz.
Gen. 12 / Xe Serie Codename Alder Lake Xe Architektur Gen. 12 Pipelines 24 - unified Kerntakt 450 - 750 (Boost) MHz Shared Memory ja API DirectX 12_1, OpenGL 4.6 Herstellungsprozess 10 nm Features QuickSync Erscheinungsdatum 03.01.2023
CPU in UHD Graphics 24EUs (Alder Lake-N) GPU Base Speed GPU Boost / Turbo Intel Processor N97 4 x ? MHz, 12 W ? MHz 1200 MHz Intel Processor N100 4 x 1000 MHz, 6 W ? MHz 750 MHz min. - max. ? MHz 750 - 1200 MHz
Benchmarks Performance Rating - 3DMark 11 + Fire Strike + Time Spy
0.5 pt (2%)
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
3DMark - 3DMark Time Spy Score
min: 345 avg: 377.9 median: 364 (1%) max: 538 Points
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
3DMark - 3DMark Time Spy Graphics
min: 304 avg: 331.1 median: 320 (1%) max: 473 Points
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 54707 avg: 57907 median: 55681 (6%) max: 79785 Points
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
3DMark - 3DMark Ice Storm Extreme Graphics
min: 21251 avg: 30932 median: 30479.5 (4%) max: 41235 Points
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
3DMark - 3DMark Cloud Gate Score
min: 6007 avg: 6805 median: 6751 (7%) max: 8596 Points
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
3DMark - 3DMark Cloud Gate Graphics
min: 7218 avg: 8532 median: 8303.5 (2%) max: 11498 Points
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
3DMark - 3DMark Fire Strike Standard Score
min: 1009 avg: 1140 median: 1127 (2%) max: 1512 Points
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
3DMark - 3DMark Fire Strike Standard Graphics
min: 1080 avg: 1209 median: 1184 (1%) max: 1646 Points
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
3DMark - 3DMark Ice Storm Graphics
min: 22501 avg: 46670 median: 46436.5 (5%) max: 62083 Points
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
3DMark 11 - 3DM11 Performance Score
min: 1626 avg: 1763 median: 1710 (2%) max: 2504 Points
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
3DMark 11 - 3DM11 Performance GPU
min: 1458 avg: 1545 median: 1488.5 (1%) max: 2233 Points
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
3DMark Vantage + 3DMark Vantage - 3DM Vant. Perf. total
min: 5527 avg: 6122 median: 5775.5 (2%) max: 8332 Points
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
3DM Vant. Perf. GPU no PhysX + 3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 4603 avg: 5188 median: 4957 (3%) max: 7213 Points
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
3DMark 05 - 3DMark 05 - Standard
min: 12034 avg: 16771 median: 17649 (19%) max: 21014 Points
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
3DMark 06 3DMark 06 - Standard 1280x1024 +
min: 8849 avg: 10419 median: 10057 (13%) max: 13452 Points
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
Unigine Valley 1.0 - Unigine Valley 1.0 DX
min: 4.1 avg: 4.8 median: 4.7 (1%) max: 5.7 fps
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
SPECviewperf 12 + SPECviewperf 12 - specvp12 sw-03
min: 20.9 avg: 21.3 median: 21.1 (5%) max: 22 fps
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
specvp12 snx-02 + SPECviewperf 12 - specvp12 snx-02
min: 2 avg: 2.1 median: 2.1 (0%) max: 2.13 fps
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
specvp12 showcase-01 + SPECviewperf 12 - specvp12 showcase-01
min: 5.71 avg: 6 median: 6 (1%) max: 6.19 fps
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
specvp12 mediacal-01 + SPECviewperf 12 - specvp12 mediacal-01
min: 2.53 avg: 2.7 median: 2.8 (1%) max: 2.83 fps
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
specvp12 maya-04 + SPECviewperf 12 - specvp12 maya-04
min: 11.4 avg: 11.6 median: 11.5 (3%) max: 12 fps
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
specvp12 energy-01 + SPECviewperf 12 - specvp12 energy-01
min: 0.15 avg: 0.2 median: 0.2 (0%) max: 0.18 fps
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
specvp12 creo-01 + SPECviewperf 12 - specvp12 creo-01
min: 8.48 avg: 8.6 median: 8.5 (3%) max: 8.69 fps
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
specvp12 catia-04 + SPECviewperf 12 - specvp12 catia-04
min: 10.9 avg: 11 median: 10.9 (2%) max: 11.3 fps
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
specvp12 3dsmax-05 + SPECviewperf 12 - specvp12 3dsmax-05
min: 13.6 avg: 14.1 median: 13.8 (2%) max: 14.9 fps
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
SPECviewperf 13 specvp13 sw-04 + SPECviewperf 13 - specvp13 sw-04
min: 27.4 avg: 27.7 median: 27.7 (7%) max: 28.1 fps
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
specvp13 snx-03 + SPECviewperf 13 - specvp13 snx-03
min: 3.6 avg: 3.7 median: 3.8 (0%) max: 3.84 fps
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
specvp13 showcase-02 + SPECviewperf 13 - specvp13 showcase-02
min: 5.69 avg: 6 median: 6 (1%) max: 6.17 fps
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
specvp13 medical-02 + SPECviewperf 13 - specvp13 medical-02
min: 2.28 avg: 2.6 median: 2.8 (1%) max: 2.84 fps
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
specvp13 maya-05 + SPECviewperf 13 - specvp13 maya-05
min: 15.9 avg: 16.4 median: 16.3 (2%) max: 17 fps
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
specvp13 energy-02 + SPECviewperf 13 - specvp13 energy-02
310 fps (100%)
...
Intel UHD Graphics 24EUs (Alder Lake-N)
specvp13 creo-02 + SPECviewperf 13 - specvp13 creo-02
min: 11.6 avg: 11.7 median: 11.7 (2%) max: 11.8 fps
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
specvp13 catia-05 + SPECviewperf 13 - specvp13 catia-05
min: 15.6 avg: 15.9 median: 15.8 (2%) max: 16.2 fps
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
specvp13 3dsmax-06 + SPECviewperf 13 - specvp13 3dsmax-06
min: 13.4 avg: 14 median: 13.7 (2%) max: 14.8 fps
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
Cinebench R10 Cinebench R10 Shading (32bit) + Cinebench R10 - Cinebench R10 Shading (32bit)
min: 7035 avg: 8399 median: 8492.5 (6%) max: 10013 Punkte
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit + Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 33.23 avg: 38.1 median: 36.8 (12%) max: 49.39 fps
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
Cinebench R15 + Cinebench R15 - Cinebench R15 OpenGL 64 Bit
min: 34.3 avg: 40.6 median: 39.8 (2%) max: 56.41 fps
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
Cinebench R15 OpenGL Ref. Match 64 Bit + Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
97.8 % (98%)
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
Basemark GPU 1.2 - Basemark GPU 1.2 Vulkan Official Medium Offscreen 1080
min: 46.4 avg: 80.6 median: 54.1 (0%) max: 217 fps
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
Basemark GPU 1.2 - Basemark GPU 1.2 Vulkan Official High Offscreen 2160
min: 3.64 avg: 5.6 median: 3.9 (1%) max: 15.3 fps
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
Geekbench 6.2 - Geekbench 6.2 GPU OpenCL
min: 3010 avg: 3430 median: 3310 (1%) max: 5145 Punkte
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
Geekbench 6.2 - Geekbench 6.2 GPU Vulkan
min: 3443 avg: 3911 median: 3802.5 (1%) max: 5822 Punkte
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
min: 222 avg: 313.8 median: 254 (1%) max: 760 Samples/s
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
min: 473 avg: 653 median: 524.5 (1%) max: 1386 Samples/s
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
ComputeMark v2.1 - ComputeMark v2.1 Result
min: 628 avg: 679 median: 655.5 (1%) max: 911 Punkte
...
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
Power Consumption - Furmark Stress Test Power Consumption - external Monitor *
min: 9.49 avg: 16.8 median: 15.8 (2%) max: 27.5 Watt
Intel UHD Graphics 24EUs (Alder Lake-N)
...
max:
0 5 10 15 20 25 30 35 Tooltip Asus BR1104CGA-N00007XA: Ø9.49 (9.22-10.9)
Minisforum Venus Series UN100L: Ø11.6 (10.7-19)
Minisforum Venus Series UN100D: Ø13.6 (12.9-16.5)
BOSGAME N95: Ø14.4 (13.4-16.7)
Minipc Union NiPoGi GK3PLUS - N95: Ø15.4 (14.9-21.1)
Beelink Mini S12 Pro: Ø15.6 (15.4-16.2)
Blackview MP80: Ø15.9 (15.1-23.2)
Geekom MiniAir 12: Ø16.3 (14.3-26.5)
Newsmay AC8F-POE: Ø17.1 (16.4-25.3)
Trigkey G4: Ø17.4 (16-28.8)
Acemagic S1: Ø27.3 (26.2-36.2)
Acemagic S1: Ø27.5 (25.5-30.3)
Power Consumption - The Witcher 3 Power Consumption - external Monitor *
min: 21.5 avg: 26.4 median: 26.5 (4%) max: 31.1 Watt
Intel UHD Graphics 24EUs (Alder Lake-N)
