NVIDIA GeForce RTX 3060 Laptop GPU
Die Nvidia GeForce RTX 3060 Laptop GPU oder 3060 Mobile (für Laptops, GN20-E3, Max-P / Max-Q) ist Anfang 2021 die dritt-schnellste mobile Ampere-Grafikkarte. Sie basiert auf den GA106 Ampere Chip und bietet 6 GB GDDR6 Grafikspeicher mit einem 192 Bit Grafikbus (mit 12 oder 14 Gbps). Sie unterstützt PCIe 4.0 und soll in zwei verschiedenen Varianten mit 60 bis 115 Watt (TGP) verfügbar sein. Als Package nutzt die Notebook-Grafikkarte GB5-256 und die Chipgröße soll 40x40mm betragen. Die GPU unterstützt eDP 1.4b zum Anschluss des internen Monitors.
Es gibt nun keine Max-Q Variante mehr (die 60 - 70 Watt Versionen heissen auch nur "Laptop GPU"), aber jede TGP-Version kann die Max-Q Technologien nutzen (Dynamic Boost, Whispermode).
Die Leistung ist abhängig von der TGP-Variante und der verwendeten Kühlung. Im Schnitt sollte sie etwa auf dem Level einer alten RTX 2070 Super Mobile liegen. Dadurch ist die Leistung bei anspruchsvollen Spielen am besten für QHD (2560x1440) und maximalen Details geeignet. Weniger anspruchsvolle Spiele können auch in 4k flüssig gespielt werden.
Der GA106 Chip bietet 3.840 FP32 ALUs wovon die Hälfte auch INT32 Befehle ausführen können (also 1.920 INT32 ALUs). Die RTX 3060 nutzt davon alle 3840 Kerne. Bei Turing konnten noch alle Shader FP32 oder INT32 ausführen. Die Raytracing und Tensor Kerne auf dem Chip wurden laut Nvidia ebenfalls verbessert. Weiters integriert der Ampere Chip einen Hardware Video-Encoder (NVENC 5. Generation für H.264 und H.265) und Decoder (7. Generation für zahlreiche Formate inklusive AV1).
Der GA106 Chip wird bei Samsung im 8nm (8N) Verfahren welches mit dem 7nm Verfahren von TSMC nicht ganz mithalten kann (z.B. von AMD genutzt, aber auch für den professionellen GA100 Ampere Chip).
GeForce RTX 3000 Serie Codename GN20-E3 GA106 Architektur Ampere Pipelines 3840 - unified TMUs 120 ROPs 48 Raytracing Cores 30 Tensor / AI Cores 120 Kerntakt 817 - 1702 (Boost) MHz Speichertakt 14000 effective = 1750 MHz Speicherbandbreite 192 Bit Speichertyp GDDR6 Max. Speichergröße 6 GB Shared Memory nein Memory Bandwidth 336 GB/s API DirectX 12_2, Shader 7.0, OpenGL 4.6 Stromverbrauch 115 Watt (60 - 115 Watt TGP) Herstellungsprozess 8 nm PCIe 4.0 Displays HDMI 2.1, DisplayPort 1.4a Features NVIDIA DLSS, NVIDIA Reflex, Resizable BAR, NVIDIA Broadcast, NVIDIA Ansel, NVIDIA ShadowPlay®, NVIDIA G-SYNC®, Advanced Optimus, Nvidia Max-Q, Dynamic Boost Notebookgröße groß (17" z.B.) Erscheinungsdatum 04.01.2021
Benchmarks Performance Rating - 3DMark 11 + Fire Strike + Time Spy
30.8 pt (35%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark - 3DMark Time Spy Score
min: 6473 avg: 8108 median: 8264 (42%) max: 9677 Points
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 86% 68% 75% 78% 79% 76% 79% 86% 83% 100% 88% 86% 89% 95%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark - 3DMark Time Spy Graphics
min: 6285 avg: 8018 median: 8181 (38%) max: 9235 Points
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 89% 69% 76% 79% 84% 78% 82% 88% 85% 100% 91% 90% 93% 95%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 116696 avg: 378734 median: 412820 (55%) max: 536666 Points
GPU TDP 80 W TDP 100 W TDP 120 W TDP 130 W 100% 97% 57% 49%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark - 3DMark Ice Storm Extreme Graphics
min: 137690 avg: 221073 median: 221073 (30%) max: 304456 Points
GPU TDP 80 W TDP 130 W 45% 100%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark - 3DMark Cloud Gate Score
min: 28859 avg: 44462 median: 44621 (48%) max: 58475 Points
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 70% 78% 59% 79% 71% 79% 74% 60% 100% 93% 81% 86% 95%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark - 3DMark Cloud Gate Graphics
min: 33126 avg: 101683 median: 108695 (44%) max: 136275 Points
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 60% 51% 36% 77% 69% 89% 80% 60% 89% 100% 63% 92% 79%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark - 3DMark Fire Strike Standard Score
min: 15062 avg: 18263 median: 18451 (44%) max: 21179 Points
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 91% 75% 77% 83% 84% 83% 85% 85% 90% 100% 90% 92% 94% 98%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark - 3DMark Fire Strike Standard Graphics
min: 16354 avg: 20280 median: 20495 (34%) max: 23109 Points
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 95% 76% 81% 84% 91% 85% 89% 82% 93% 99% 91% 92% 98% 100%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark - 3DMark Ice Storm Graphics
min: 124176 avg: 184037 median: 139478 (19%) max: 333015 Points
GPU TDP 80 W TDP 85 W TDP 125 W TDP 130 W 42% 37% 42% 100%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark - 3DMark Wild Life Unlimited
52547 Points (44%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark - 3DMark Wild Life Extreme Unlimited
min: 15263 avg: 16429 median: 16763 (36%) max: 17261 Points
GPU TDP ? TDP 130 W 100% 97%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark - 3DMark Night Raid
44997 Points (54%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
3DMark - 3DMark Night Raid Graphics Score
86045 Points (48%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
3DMark 11 - 3DM11 Performance Score
min: 14164 avg: 22586 median: 22367 (45%) max: 28541 Points
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 83% 79% 82% 76% 73% 78% 80% 87% 65% 100% 84% 82% 85% 97%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark 11 - 3DM11 Performance GPU
min: 13799 avg: 26329 median: 26862 (38%) max: 30772 Points
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 88% 75% 83% 81% 84% 83% 87% 93% 68% 100% 93% 90% 96% 99%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark Vantage + 3DMark Vantage - 3DM Vant. Perf. total
57333 Points (17%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DM Vant. Perf. GPU no PhysX + 3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
68627 Points (53%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark 05 - 3DMark 05 - Standard
48758 Points (68%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
3DMark 06 3DMark 06 - Standard 1280x1024 +
min: 37418 avg: 44177 median: 46503 (70%) max: 48609 Points
GPU TDP 80 W TDP 100 W TDP 105 W 100% 96% 77%
...
NVIDIA GeForce RTX 3060 Laptop GPU
Unigine Valley 1.0 - Unigine Valley 1.0 DX
97.4 fps (42%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
Blender - Blender 3.3 Classroom CUDA *
min: 54 avg: 66 median: 55 (14%) max: 89 Seconds
GPU TDP ? TDP 95 W TDP 115 W 112% 100% 111%
NVIDIA GeForce RTX 3060 Laptop GPU
Blender - Blender 3.3 Classroom OPTIX *
min: 32 avg: 40 median: 32 (23%) max: 56 Seconds
GPU TDP ? TDP 95 W TDP 115 W 128% 100% 128%
...
NVIDIA GeForce RTX 3060 Laptop GPU
Blender - Blender 3.3 Classroom HIP *
481 Seconds (72%)
NVIDIA GeForce RTX 3060 Laptop GPU
SPECviewperf 12 + SPECviewperf 12 - specvp12 sw-03
63.4 fps (28%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
specvp12 snx-02 + SPECviewperf 12 - specvp12 snx-02
9.2 fps (3%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
specvp12 showcase-01 + SPECviewperf 12 - specvp12 showcase-01
99.6 fps (32%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
specvp12 mediacal-01 + SPECviewperf 12 - specvp12 mediacal-01
47.1 fps (29%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
specvp12 maya-04 + SPECviewperf 12 - specvp12 maya-04
117 fps (41%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
specvp12 energy-01 + SPECviewperf 12 - specvp12 energy-01
10.4 fps (26%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
specvp12 creo-01 + SPECviewperf 12 - specvp12 creo-01
55.2 fps (30%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
specvp12 catia-04 + SPECviewperf 12 - specvp12 catia-04
82.7 fps (28%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
specvp12 3dsmax-05 + SPECviewperf 12 - specvp12 3dsmax-05
180 fps (37%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
SPECviewperf 13 specvp13 sw-04 + SPECviewperf 13 - specvp13 sw-04
93.2 fps (43%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
specvp13 snx-03 + SPECviewperf 13 - specvp13 snx-03
16.7 fps (3%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
specvp13 showcase-02 + SPECviewperf 13 - specvp13 showcase-02
98.1 fps (31%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
specvp13 medical-02 + SPECviewperf 13 - specvp13 medical-02
57.2 fps (31%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
specvp13 maya-05 + SPECviewperf 13 - specvp13 maya-05
239 fps (42%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
specvp13 energy-02 + SPECviewperf 13 - specvp13 energy-02
20.3 fps (15%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
specvp13 creo-02 + SPECviewperf 13 - specvp13 creo-02
179 fps (46%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
specvp13 catia-05 + SPECviewperf 13 - specvp13 catia-05
117 fps (25%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
specvp13 3dsmax-06 + SPECviewperf 13 - specvp13 3dsmax-06
180 fps (37%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
SPECviewperf 2020 specvp2020 solidworks-05 4k + SPECviewperf 2020 - specvp2020 solidworks-05 4k
182 fps (54%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
specvp2020 snx-04 4k + SPECviewperf 2020 - specvp2020 snx-04 4k
16.8 fps (3%)
NVIDIA GeForce RTX 3060 Laptop GPU
specvp2020 medical-03 4k + SPECviewperf 2020 - specvp2020 medical-03 4k
26.5 fps (51%)
NVIDIA GeForce RTX 3060 Laptop GPU
specvp2020 maya-06 4k + SPECviewperf 2020 - specvp2020 maya-06 4k
264 fps (59%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
specvp2020 energy-03 4k + SPECviewperf 2020 - specvp2020 energy-03 4k
20.4 fps (15%)
NVIDIA GeForce RTX 3060 Laptop GPU
specvp2020 creo-03 4k + SPECviewperf 2020 - specvp2020 creo-03 4k
84.5 fps (52%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
specvp2020 catia-06 4k + SPECviewperf 2020 - specvp2020 catia-06 4k
52.3 fps (43%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
specvp2020 3dsmax-07 4k + SPECviewperf 2020 - specvp2020 3dsmax-07 4k
82.5 fps (49%)
NVIDIA GeForce RTX 3060 Laptop GPU
Cinebench R10 Cinebench R10 Shading (32bit) + Cinebench R10 - Cinebench R10 Shading (32bit)
min: 4955 avg: 11641 median: 14081 (10%) max: 15888 Punkte
GPU TDP ? TDP 80 W TDP 130 W 31% 100% 89%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit + Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 77 avg: 124.6 median: 140 (51%) max: 156.74 fps
GPU TDP ? TDP 80 W TDP 130 W 89% 100% 49%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
Cinebench R15 + Cinebench R15 - Cinebench R15 OpenGL 64 Bit
min: 99.5 avg: 170.1 median: 173 (47%) max: 219 fps
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 86% 100% 95% 87% 83% 93% 87% 76% 89% 95% 50% 68% 76% 91%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
Cinebench R15 OpenGL Ref. Match 64 Bit + Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
99.6 % (100%)
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 100% 100% 100% 100% 100% 100% 100% 100% 100% 100% 100% 100% 100% 100%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
Power Consumption - Furmark Stress Test Power Consumption - external Monitor *
min: 94.1 avg: 145.5 median: 149 (23%) max: 202 Watt
GPU TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 125 W TDP 130 W TDP 140 W 117% 116% 113% 107% 108% 111% 105% 106% 101% 102% 104% 100%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
